Women's Packable Raincoat with Hood
This product page details the technical specifications, material properties, and functional design of a women's packable raincoat with integrated hood, intended for light to moderate precipitation in variable outdoor conditions. The garment is engineered for portability without compromising essential weather protection, targeting users who require reliable, on-demand rain defense in urban, travel, or light outdoor environments.
Material Composition and Construction
The raincoat utilizes a 2.5-layer laminate system: an outer shell of 100% nylon micro-ripstop (70D x 70D) with a durable water repellent (DWR) finish, a hydrophilic polyurethane (PU) membrane for moisture vapor transmission, and an inner protective scrim. This construction achieves a hydrostatic head rating of 5,000 mm and a moisture vapor transmission rate (MVTR) of 3,000 g/m²/24h under standard test conditions (JIS L 1099 B-1). The DWR treatment is fluorocarbon-free, meeting OEKO-TEX® Standard 100 requirements for skin-contact textiles.
Seams are fully sealed with 12mm wide thermoplastic polyurethane (TPU) tape applied via heat bonding, ensuring continuous waterproof integrity at stitch lines. The fabric weighs 115 g/m², contributing to the garment’s packability while maintaining abrasion resistance comparable to 60D nylon taslan in Martindale testing (>15,000 cycles). No padding or insulation is included, as the design prioritizes breathability and minimal bulk for active use in mild temperatures (5°C to 20°C).
Design Features and Functional Details
The hood is integrated into the collar structure with a three-point adjustment system: elastic drawcord at the rear, adjustable toggles at the temples, and a stiffened brim via embedded polyethylene (PE) film (0.3mm thickness) to maintain shape and deflect rain from the face. When not in use, the hood folds neatly into the collar without creating bulk. The coat features a center-front zipper with a storm flap secured by hidden magnetic closures (neodymium, 5mm diameter) to prevent water ingress along the zipper coil.
Ventilation is provided through two underarm eyelets (6mm diameter, laser-cut, reinforced with bar-tack stitching) to promote air circulation during exertion. Cuffs are finished with 15mm wide elasticized lycra binding to seal against water entry while allowing glove compatibility. The hem includes a adjustable drawcord with cord locks positioned inside the side seam pockets to maintain a clean exterior profile. Reflective detailing consists of 10mm wide prismatic tape applied to the upper back and sleeve cuffs for low-light visibility, compliant with EN 13356:2001 standards for reflective accessories.
Packability and Storage System
The raincoat packs into its own left-hand pocket, which transforms into a stuff sack via an inverted zipper and internal elastic loop. When packed, the garment measures approximately 18cm x 12cm x 6cm (LxWxH) and weighs 180g (±10g) for size M. The stuff sack features a silicone-coated nylon base for water resistance and a lockable drawcord closure. This packing system eliminates the need for separate storage bags and ensures the coat remains accessible and protected from abrasion or contamination when stored in backpacks, glove compartments, or travel luggage.
The packing process takes under 15 seconds for trained users and does not require folding along specific crease lines, reducing user error. The fabric exhibits minimal memory deformation after repeated packing cycles (tested over 50 cycles), retaining 95% of its original drape and loft when unpacked, as measured by visual recovery assessment under standardized lighting.
Size Range and Fit Characteristics
The raincoat is offered in sizes XS through XXL, graded using a standard women’s missy block with adjustments for layered wear. Key dimensions for size M: chest circumference 108cm, sleeve length 82cm (from center back neck), and back length 72cm. The cut follows a semi-fitted silhouette with 8cm of ease at the chest and 6cm at the hip to accommodate light mid-layers (e.g., fleece or lightweight down) without restricting movement. Shoulder slope is set at 15 degrees to align with typical female posture, reducing fabric pull at the neckline during arm movement.
The pattern includes a 2cm curved hem drop at the back for increased coverage when seated or bending. All sizes maintain consistent hood proportions and adjustment range to ensure proper fit across the size spectrum. Garment measurements are taken flat on a relaxed state, following ASTM D5587-19 standards for apparel measurement. Custom sizing is available upon request for volume orders, with adjustments possible in 2cm increments for length and girth.
Quality Control and Testing Protocols
Each batch undergoes incoming material inspection for hydrostatic head, DWR durability (20 wash cycles per AATCC 135), and colorfastness to light (minimum 4 grey scale per ISO 105-B02). In-process checks include seam seal integrity verification via electrical leak testing (100V DC) and stitch density audits (minimum 8 stitches/cm on main seams). Final inspection includes functional testing of zippers, drawcords, and storm flaps, along with dimensional stability assessment after one wash cycle (30°C, gentle tumble).
The product is manufactured under ISO 9001:2015 certified processes, with traceability maintained from raw material lot to finished garment. No PFCs, formaldehyde, or azo dyes are used in production, complying with ZDHC MRSL Level 2 restrictions. Packaging uses 100% recycled polybags (LDPE #4) and soy-based ink for labeling. While no third-party performance certification (e.g., Gore-Tex®, eVent®) is claimed, all test data is available for review upon request under NDA for qualified B2B inquiries.
| Parameter | Typical Value | Test Standard |
|---|---|---|
| Hydrostatic Head | 5,000 mm | JIS L 1099 B-1 |
| MVTR | 3,000 g/m²/24h | JIS L 1099 B-1 |
| Fabric Weight | 115 g/m² | ASTM D3776 |
| Packed Volume (Size M) | 1,296 cm³ | Internal Measurement |
| Packed Weight (Size M) | 180g ±10g | ASTM D4964 |
| Reflective Coefficient | >250 cd/lx/m² | EN 13356:2001 |
Applications and Use Case Suitability
This raincoat is suited for urban commuting, travel, and light recreational use where sudden showers are expected but prolonged exposure to heavy rain or wind is unlikely. Its breathability profile makes it appropriate for active use such as walking, cycling, or hiking in temperatures above 5°C, where overheating from non-breathable rainwear would be a concern. The packable nature supports inclusion in emergency kits, daypacks, or vehicle storage for unpredictable weather, aligning with the "layering principle" in outdoor preparedness.
It is not designed for prolonged exposure to heavy precipitation (>10mm/hr), high-wind environments, or activities requiring technical mountaineering protection (e.g., alpine climbing, skiing). The absence of insulation limits its use in cold/wet conditions without an insulating mid-layer. For industrial or occupational use (e.g., field services, logistics), it serves as a secondary rain layer over high-visibility vests or uniforms when primary waterproof gear is not required or practical to carry continuously.
