Factory Direct Red Waterproof Coat Womens
Factory Direct Red Waterproof Coat for Women
This women's red waterproof coat is manufactured for direct factory supply, designed to meet the performance demands of outdoor work environments where weather protection and mobility are critical. The garment combines a permanently bonded polyurethane (PU) membrane with a 100% polyester outer shell, delivering a hydrostatic head rating of 8,000 mm and moisture vapor transmission rate (MVTR) of 5,000 g/m²/24h under standard test conditions (JIS L 1099 B-1). Seams are fully taped with 20mm-wide heat-activated polyurethane tape to prevent water ingress at stitch points, a requirement for prolonged exposure to rain or wet conditions in industrial settings.
The coat features a storm flap over the front zipper, secured with magnetic closures to reduce wind-driven water penetration, and adjustable hook-and-loop cuffs to seal against moisture at the wrists. A detachable insulated liner, composed of 150gsm polyester fleece, allows adaptation to temperatures ranging from -5°C to 15°C when worn together, while the shell alone provides effective protection in milder climates. All components are sourced from ISO 9001-certified suppliers, and final assembly occurs in a facility audited for ISO 14001 environmental management, ensuring traceability and consistency across production batches.
Technical Specifications
| Parameter | Value | Test Standard |
|---|---|---|
| Hydrostatic Head | 8,000 mm | JIS L 1092 B-1 |
| Moisture Vapor Transmission (MVTR) | 5,000 g/m²/24h | JIS L 1099 B-1 |
| Seam Tape Width | 20 mm | Internal QC |
| Outer Shell Material | 100% Polyester (150D) | ISO 2076 |
| Membrane Type | Polyurethane (PU) Lamination | ISO 1421 |
| Liner Material (Detachable) | 150gsm Polyester Fleece | ISO 11092 |
| Closure Type | YKK® Vislon Zipper + Storm Flap | Manufacturer Spec |
| Cuff Adjustment | Hook-and-Loop | Internal Design |
Design Rationale for Industrial Use
The 8,000 mm hydrostatic head rating is selected based on field data from logistics, utility, and construction sectors, where workers encounter sustained rainfall exceeding 50 mm/hour for periods up to 4 hours. This rating ensures no penetration occurs under such conditions, as validated by ISO 811 testing. The MVTR of 5,000 g/m²/24h balances breathability with waterproofing, reducing internal condensation during moderate physical activity — a common issue in non-breathable rainwear that leads to discomfort and reduced wear time.
The detachable liner system addresses seasonal variability without requiring multiple garment inventories. In colder climates, the fleece liner adds approximately 3.5 clo of thermal insulation (measured via ISO 11092), extending usable temperature range downward by 10°C. The liner attaches via hidden snap tabs at the collar, cuffs, and waist, maintaining the coat’s clean exterior profile when removed. This modular approach supports lean inventory practices for distributors and reduces SKU complexity for end-users managing seasonal workforces.
Colorfastness of the red dye is tested to ISO 105-B02 (light exposure) and ISO 105-C06 (washing), achieving a minimum rating of 4/5 after 20 cycles. This ensures visibility retention in safety-critical roles where high-visibility color coding is used for role identification, such as in traffic control or site supervision. The PU coating is formulated without phthalates or heavy metals, complying with REACH Annex XVII restrictions for consumer safety in prolonged skin contact scenarios.
Quality Control and Manufacturing Notes
- Each roll of fabric undergoes 100% visual inspection for defects under 500 lux lighting before cutting, with a maximum allowable flaw density of 2 points per 100 linear meters.
- Seam taping is performed using calibrated hot-air welders set to 280±10°C and 3.5 bar pressure, with peel strength tested per batch to exceed 8 N/25mm (ISO 11339-3).
- Finished garments receive a 3-point water spray test (AATCC 35) on critical zones (shoulders, chest, back) to verify membrane integrity post-assembly.
- Dimensional stability is checked after 3 wash cycles at 40°C; shrinkage is limited to ≤2% in warp and weft directions (ISO 5077).
- Batch traceability is maintained via QR codes on internal labels, linking to fabric source, coating date, and QC test results.
Applications in Work Environments
This coat is routinely specified for outdoor personnel in municipal services (road maintenance, waste collection), utility meter reading, and agricultural inspection crews who require uninterrupted mobility during precipitation. Unlike heavier PVC-based rainwear, the laminated PU shell maintains flexibility below 0°C, preventing stiffness that restricts arm movement during tool operation or ladder climbing. The absence of plasticizers in the coating eliminates cracking risk over time, a common failure mode in low-cost alternatives after 6–12 months of UV exposure.
In logistics and warehouse operations with open loading docks, the coat’s breathability prevents heat buildup during intermittent activity, while the storm flap and sealed cuffs protect against wind-driven rain common in coastal or high-altitude facilities. The red color is often used as a secondary identifier for shift leads or safety observers, complementing primary high-visibility vests without compromising the garment’s primary weather protection function. These use cases informed the selection of seam placement, pocket positioning, and hood geometry to avoid interference with hard hats or communication headsets.
Customization and Ordering Information
Standard production includes sizes XS to 3XL in the specified red (Pantone 18-1663 TCX). Custom color matching is available for orders exceeding 200 units, subject to dye lot feasibility and minimum pigment weight requirements. Alternative shell materials such as nylon taslan or recycled polyester can be substituted upon request, with corresponding adjustments to hydrostatic head and MVTR values provided in a revised technical datasheet. Hood configuration (fixed, stowable, or removable) and pocket layout (internal, external, radio-access) are modifiable based on workflow needs.
Lead time for standard orders is 25–30 working days after sample approval and deposit receipt. Export packaging uses multi-wall corrugated cartons with internal polyethylene lining to prevent moisture damage during transit, compliant with ISTA 3A standards for general cargo. Sample garments are available upon request, with shipping costs borne by the requester; sample lead time is 7–10 days for standard configurations. All quotations include FOB pricing from the manufacturing port, with freight and insurance arranged separately unless specified.
