China Womens Black Raincoat With Hood
China Women's Black Raincoat with Hood
This women's black raincoat with hood is designed for industrial and professional use in wet environments where reliable protection and ease of movement are required. Constructed from 100% polyester with a polyurethane (PU) coating, the fabric provides a hydrostatic head rating of 5,000 mm, ensuring resistance to moderate to heavy rainfall without compromising breathability. The coating is applied uniformly via roll-to-roll lamination, minimizing weak points and enhancing durability against abrasion and flex fatigue.
Seams are fully taped using 20mm-wide heat-activated PU tape, applied with precision rollers to achieve a bond strength exceeding 8 N/cm, preventing water ingress at stitch lines. The hood features a three-panel design with a semi-rigid visor molded from low-density polyethylene (LDPE), maintaining shape in wind while allowing peripheral visibility. Adjustment is via two lockable drawcords with cord stops, enabling one-handed tightening even when wearing gloves.
The raincoat includes a storm flap over the front zipper, secured by hidden magnetic closures at the top and bottom and reinforced with snap buttons along the length. The zipper itself is a coated nylon coil type with a water-resistant finish, rated for 5,000+ cycles without failure. Underarm ventilation consists of two 8cm zippered openings protected by storm flaps, reducing internal condensation during high-activity tasks.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Outer Shell Material | 100% polyester filament yarn, 150D × 150D, plain weave |
| Coating Type | Polyurethane (PU), 0.15mm thickness |
| Hydrostatic Head | 5,000 mm (JIS L 1092 Method B) |
| Moisture Vapor Transmission Rate (MVTR) | 3,500 g/m²/24h (ASTM E96) |
| Seam Tape Width | 20 mm heat-activated PU tape |
| Zipper Type | Coated nylon coil, #5 size, water-resistant finish |
| Hood Construction | Three-panel, LDPE visor, adjustable drawcord with cord stops |
| Ventilation | Two underarm zippered openings with storm flaps |
| Available Sizes | S (155/80A), M (160/84A), L (165/88A), XL (170/92A), XXL (175/96A) – based on GB/T 1335 |
| Length (Center Back) | 82 cm (M), graded ±2 cm per size |
Material Performance and Durability
The polyester base fabric uses continuous filament yarns with a tight plain weave (approximately 180 ends per inch), providing high tear strength (warp: 35 N, weft: 30 N via ISO 13937-2) and resistance to snagging. The PU coating is formulated with additives to resist UV degradation and hydrolysis, maintaining flexibility down to -20°C and preventing brittleness after prolonged exposure. Colorfastness to light and washing exceeds Grade 4 on the grey scale, ensuring the black finish does not fade noticeably under industrial laundering or outdoor storage.
Abrasion resistance is tested per ISO 12947-2 (Martindale), achieving over 20,000 cycles before noticeable surface wear, suitable for contact with rough surfaces or equipment. The coating adhesion to the substrate exceeds 4.0 N/mm (ISO 2411), reducing the risk of delamination under flex or thermal cycling. These properties support a service life of 12–18 months under regular outdoor use in construction, logistics, or utility work, depending on exposure intensity.
Design for Industrial Use
The raincoat’s cut follows a relaxed fit with articulated shoulders and sleeves, allowing unrestricted movement when carrying tools or wearing layers underneath. Sleeve cuffs are adjustable via hook-and-loop tabs, enabling a seal over gloves or wristwear without restricting circulation. The back features a single center pleat and side gussets, increasing mobility when bending or reaching, critical for tasks such as meter reading, inspection, or material handling in wet conditions.
Reflective elements are available as an option: 50mm-wide silver reflective tape compliant with EN ISO 20471 Class 2, positioned on the shoulders, sleeves, and back for low-visibility environments. These are thermally bonded using heat-activated adhesive, ensuring durability through 50+ wash cycles. Pockets include two front slash pockets with drainage holes and a secure interior chest pocket with zip closure, designed to protect radios, documents, or electronic devices from moisture.
Customization Options
- Fabric weight: Available from 180 g/m² to 240 g/m² based on durability needs
- Hydrostatic head: Upgradable to 8,000 mm or 10,000 mm for extreme weather
- Coating: Optional PVC or TPU layers for chemical resistance
- Color: Custom dye matching available (Pantone or RAL)
- Branding: Silk screen, heat transfer, or embroidery on chest, back, or sleeves
- Size grading: Custom proportions for regional body types
- Packaging: Individual poly bags, bulk cartons, or hanger packing
Quality Control and Testing
Each batch undergoes raw material inspection, including coating thickness measurement (via micrometer) and hydrostatic head testing on fabric samples. In-line checks monitor seam tape adhesion and zipper alignment during sewing. Final inspection includes water spray testing (AATCC 35) on finished garments, verifying no leakage at critical points after 5 minutes of exposure. Measurements are taken against a tolerance chart to ensure dimensional consistency across sizes, with length and chest circumference held to ±1.5 cm.
Color consistency is verified using a spectrophotometer (ΔE < 1.5) to ensure batch-to-batch uniformity. Functional testing includes 10 cycles of washing and drying (per ISO 6330) followed by re-testing of hydrostatic head and breathability to confirm performance retention. All test records are retained for traceability, and non-conforming items are segregated for root cause analysis. These procedures support consistent performance in field applications where reliability is critical.
Applications
This raincoat is suited for outdoor personnel in utilities, telecommunications, and municipal services who require protection from rain while maintaining visibility and mobility. Workers in logistics and freight handling benefit from the abrasion-resistant fabric when loading/unloading goods in wet yards or docks. The adjustable hood and storm flap design make it suitable for forklift operators or crane operators who need clear upward vision without water runoff impairing sight.
In construction, it provides a practical layer for site supervisors, surveyors, and maintenance crews working in variable weather. The option for reflective trim allows use in low-light or nighttime operations near traffic or machinery. For environmental monitoring or field research, the breathable coating helps manage microclimate inside the garment during extended wear, reducing discomfort during prolonged observation tasks.
