Raincoat For Men With Pants
Raincoat for Men with Integrated Pants – Technical Specification
This product combines a waterproof jacket and trousers into a single-piece rain suit designed for continuous wear in wet industrial environments. The integrated construction eliminates gaps at the waist, reducing water ingress during prolonged exposure to rain, spray, or high-humidity conditions. Intended for use by field technicians, utility workers, and transportation personnel requiring full-body protection without the complexity of separate garments.
Material Composition and Performance Characteristics
The outer shell is constructed from 100% polyester fabric with a polyurethane (PU) coating applied to both sides, achieving a hydrostatic head rating of 8,000 mm. This measurement indicates the water pressure the fabric can withstand before leakage occurs, suitable for moderate to heavy rainfall. The inner layer features a brushed polyester lining for improved wear comfort and moisture wicking, reducing condensation buildup during extended use. Seams are fully sealed with 15mm wide PU tape using heat-bonding technology to prevent capillary action along stitch lines.
The fabric exhibits a tensile strength of 45 N warp and 38 N weft (ASTM D5034), ensuring resistance to tearing under snagging or abrasion. Breathability is rated at 3,000 g/m²/24hr (ASTM E96), allowing limited vapor transmission to reduce heat stress during active work. The material maintains flexibility down to -20°C, preventing brittleness in cold environments. All components are free from phthalates and heavy metals, complying with REACH and Oeko-Tex Standard 100 requirements.
Design Features and Functional Details
The jacket includes a storm flap over the front zipper, secured with snap buttons to prevent water penetration through the zipper teeth. The zipper itself is a coated nylon coil type with a water-resistant finish. Adjustable cuffs feature dual-layer hook-and-loop closures, allowing tight sealing over gloves or wrists. The hood is three-piece, adjustable via drawcord and toggles, with a reinforced peak to shield the face from rain. Peripheral visibility is enhanced by two 50mm wide reflective strips on the chest, back, and sleeves, meeting EN ISO 20471 Class 2 requirements for daytime and nighttime conspicuity.
The trousers feature an elasticated waistband with internal drawcord for adjustable fit, reinforced belt loops for tool carrying, and articulated knees for improved mobility during kneeling or crouching. Ankle openings are adjustable via snap-button tabs, enabling secure fit over boots. Reinforced patches are applied to the seat and inner thighs using the same PU-coated polyester to resist abrasion from frequent contact with rough surfaces. All pockets are internal and accessed via vertical zippers with storm flaps, protecting contents from water ingress.
Sizing and Fit Specifications
The rain suit is available in five standard sizes: S, M, L, XL, XXL, based on chest circumference and height measurements. The following table provides typical body dimensions for each size, measured in centimeters. Garment dimensions include ease allowances for movement and layering underneath. Custom sizing is available upon request for non-standard body proportions or specific operational requirements.
| Size | Chest (cm) | Height (cm) | Waist (cm) | Inseam (cm) |
|---|---|---|---|---|
| S | 88–94 | 165–170 | 76–82 | 76 |
| M | 94–100 | 170–175 | 82–88 | 78 |
| L | 100–106 | 175–180 | 88–94 | 80 |
| XL | 106–112 | 180–185 | 94–100 | 82 |
| XXL | 112–118 | 185–190 | 100–106 | 84 |
Applications in Industrial Environments
This rain suit is commonly used in utility maintenance operations where workers are exposed to prolonged outdoor conditions during storm recovery, line inspection, or equipment repair. The full-length design prevents water from entering at the waist when bending or reaching overhead, a frequent failure point in separate jacket-and-pants systems. In transportation and logistics, it protects personnel during cargo loading/unloading in open yards or rail terminals, where wind-driven rain can penetrate conventional outerwear.
Municipal workers engaged in street cleaning, drainage maintenance, or emergency response benefit from the suit’s durability and ease of decontamination. The smooth PU coating allows for quick rinsing and wiping down after exposure to mud, oil, or debris. In agricultural settings, such as livestock management or greenhouse maintenance, the suit provides protection against spray from irrigation systems or cleaning chemicals, while the breathable lining reduces discomfort during extended shifts.
Quality Control and Manufacturing Considerations
Each batch of fabric undergoes hydrostatic head testing before cutting to ensure coating uniformity and adhesion. Seam sealing is verified using a dye penetration test under pressure to confirm continuous waterproofing along all stitched joints. Zippers and closures are cycle-tested for 500 operations to assess durability and water resistance retention. Final inspection includes a 3-minute spray test per ISO 811, where the garment is subjected to uniform water flow while inspectors check for internal moisture accumulation.
Dimensional stability is assessed after five wash cycles at 30°C per ISO 6330, ensuring minimal shrinkage or distortion that could affect fit or seam integrity. Colorfastness to light and rubbing is evaluated to maintain visibility and appearance over time. All testing follows internally documented procedures aligned with ISO 9001 quality management principles. Test reports are available for review upon request, though specific values may vary based on fabric lot and production parameters.
Customization Options and Ordering Information
Standard color options include high-visibility yellow, orange, and navy blue, with reflective tape configured to meet EN ISO 20471 Class 2. Alternative colors such as gray, olive, or black are available for non-visibility-critical applications, though these do not include reflective detailing unless specifically requested. Custom logo placement is possible via screen printing or heat transfer on the chest, back, or sleeves, subject to minimum order quantities and artwork specifications.
Adjustments to sleeve length, trouser inseam, or hood depth can be accommodated for specialized roles or ergonomic needs. Alternative seam sealing methods, such as ultrasonic welding or silicone tape, are available upon request for environments requiring chemical resistance beyond standard PU. Packaging options include individual polybags with hanging hooks or bulk packing in cartons, with labeling compliant with ISO 17491 for identification and traceability.
Lead time for standard configurations is typically 3–4 weeks from approved artwork and size confirmation. Samples are available for evaluation, with costs credited against subsequent bulk orders. Quotations require detailed specifications including size distribution, color preferences, logo details, and any required certifications. Contact technical sales for project-specific consultations or to discuss environmental performance requirements not covered in standard documentation.
