This industrial-grade raincoat combines extended length padding with a fully integrated hood to provide comprehensive protection against prolonged exposure to wet and cold conditions. Designed for workers in outdoor maintenance, utility services, and transportation sectors, it addresses the dual challenges of thermal retention and water ingress prevention through engineered material systems and strategic seam sealing.

The garment utilizes a three-layer composite fabric: an outer polyester shell with durable water repellent (DWR) treatment, a middle polyurethane membrane rated for 10,000mm hydrostatic head resistance, and an inner polyester fleece lining with 180gsm synthetic insulation. This construction achieves a balanced performance profile where waterproofing is maintained without compromising breathability, measured at 5,000g/m²/24hr moisture vapor transmission rate under standard testing conditions (ISO 811).

Critical seam integrity is ensured through ultrasonic welding and heat-sealed tape application on all stitch lines, eliminating capillary pathways for water migration. The hood features a three-point adjustment system—vertical drawcord at the crown, lateral tensioners at the temples, and a rigidified brim insert—to maintain facial visibility while preventing wind-driven rain entry. Sleeve cuffs incorporate adjustable hook-and-loop closures paired with internal lycra gaskets to seal against glove interfaces.

Technical Specifications

The padding system employs discontinuous filament polyester insulation engineered to maintain loft under compression, critical when wearing backpacks or harnesses. Thermal retention is quantified via CLO value testing, yielding 0.85 clo at -5°C ambient temperature with 1m/s wind speed, sufficient for active work in sub-zero conditions without overheating during exertion. Color options include high-visibility orange (EN ISO 20471 Class 2 compliant) and navy blue, both using UV-stable pigments to resist fading under prolonged solar exposure.

Applications

Utility workers performing line maintenance in precipitation benefit from the coat’s extended length, which protects lower torso and thighs when working from elevated platforms or kneeling in wet grass. The hood’s rigid brim prevents water runoff from obstructing vision during overhead tasks, while the sealed seams prevent saturation when brushing against damp vegetation or equipment.

Transportation and logistics personnel engaged in cargo securing or vehicle inspection in open yards gain protection from wind-driven rain and spray from passing traffic. The adjustable cuff system interfaces safely with high-visibility vests and radio harnesses without creating snag points, and the insulation prevents conductive heat loss when handling cold metal surfaces during winter operations.

Municipal services crews involved in roadside drainage clearance or winter gritting operations require garments that resist abrasion from gravel and resist saturation during extended shifts. The outer shell’s 300D polyester denier provides tear resistance exceeding 25N (ASTM D2261), and the DWR treatment retains 80% effectiveness after 20 wash cycles, reducing maintenance frequency and replacement costs over the product lifecycle.

Customization Options

Beyond standard configurations, the raincoat supports project-specific adaptations including reinforced chest pockets with drainage grommets for tool storage, detachable fleece liners for seasonal versatility, and integration of reflective tape patterns compliant with ANSI/ISEA 107-2020 for enhanced conspicuity in low-light environments. Sleeve length and torso taper can be modified to accommodate layered PPE systems such as arc-flash harnesses or fall-arrest equipment.

Closure systems are available in YKK aquaguard zippers with storm flaps or heavy-duty hook-and-loop fronts for environments where metal components pose contamination risks (e.g., food processing cleanrooms). Interior labeling options include RFID-enabled tracking tags for inventory management in large-scale operations, and care labels can be printed in multiple languages to meet regional regulatory requirements for PPE documentation.

Quality Assurance

Each production lot undergoes hydrostatic head testing on three randomly selected units per 1,000 pieces, with batch rejection if any sample falls below 9,000mm. Seam seal integrity is verified using dye penetration testing under 20kPa pressure for 5 minutes, and insulation uniformity is assessed via thermal imaging to detect cold spots exceeding 3°C variance across the back panel. These protocols exceed baseline EN 343:2019+A1:2020 requirements for Class 3,1 waterproof breathable protective clothing.

Colorfastness to washing and light is monitored using AATCC standards, with delta-E values tracked to ensure visual consistency across shipments. Dimensional stability is evaluated after five wash/dry cycles at 60°C, with length and chest measurements constrained to <2% shrinkage to maintain fit integrity over time. All test records are retained for traceability and available for customer audit upon request.

Material Composition

• Outer Shell: 100% polyester, 300D ripstop weave, DWR finish (C6-based)
• Membrane: Thermoplastic polyurethane (TPU), 10µm thickness
• Lining: 100% polyester fleece, 200gsm
• Insulation: Polyester hollow fiber, 180gsm, 12mm loft
• Seal Tape: Polyester hot-melt adhesive, 20mm width
• Hardware: YKK zippers, nylon cord locks, polyester webbing

The TPU membrane is solvent-free laminated to prevent delamination under flex stress, and the insulation undergoes silicone treatment to resist clumping when wet. Metal-free hardware options are available for MRI-compatible or explosive atmosphere environments, utilizing reinforced nylon buckles and plastic-coated snap fasteners. All materials comply with REACH and Oeko-Tex Standard 100 requirements for restricted substances.

Inquiry

For technical datasheets, size charts, or to discuss customization requirements for your operational environment, contact our engineering team. Provide details on expected exposure conditions, layering systems, and any regulatory standards applicable to your region to receive a tailored specification review.

Request Technical Consultation
