The China Hunter kids yellow raincoat is engineered for children aged 3 to 8 years, providing reliable protection against light to moderate rainfall in urban and suburban environments. Its design prioritizes visibility, mobility, and durability for daily use during wet weather conditions.

Constructed from a 0.18mm thick polyurethane-coated polyester fabric, the raincoat achieves a hydrostatic head rating of 2,000mm, ensuring resistance to water penetration under typical drizzle and shower conditions while maintaining breathability through micro-perforated backing.

The outer layer consists of 100% polyester filament yarn with a plain weave structure, coated on the inner surface with a thermoplastic polyurethane (TPU) layer. This coating provides consistent water resistance without the stiffness associated with PVC alternatives, allowing flexibility across temperatures from -5°C to +40°C.

Seams are sealed using ultrasonic welding rather than traditional tape or glue, eliminating potential delamination points and ensuring uniform waterproof integrity along all stitched junctions. The coating adhesion exceeds 3.5 N/mm as measured by ASTM D903 peel testing.

The fabric demonstrates a tear strength of 8.2 N in the warp direction and 6.7 N in the weft direction (ASTM D2261), sufficient to withstand routine handling by active children while resisting propagation of small punctures or snags.

The raincoat incorporates a three-panel hood with adjustable drawcords at the perimeter, allowing secure fit without obstructing peripheral vision. The hood brim is reinforced with a 2mm flexible polyethylene insert to maintain shape and deflect rain away from the face.

Reflective strips totaling 40cm in length are positioned on the shoulders, back, and sleeves, meeting EN 1150:1999 standards for visibility in low-light conditions. These strips retain reflectivity after 25 wash cycles at 30°C.

Snap-button closures are used along the front placket instead of zippers to eliminate pinch points and simplify operation for small hands. Each snap withstands 15N of lateral force before disengagement, balancing security with easy release.

Available in three size ranges based on child height: 90-100cm (Size S), 110-120cm (Size M), and 130-140cm (Size L). Each size includes a 5cm growth allowance in the torso and sleeve length to accommodate seasonal use.

Sleeve length is measured from the center back neck to the wrist cuff, ranging from 32cm (S) to 40cm (L). Body length from shoulder seam to hem measures 42cm (S), 48cm (M), and 54cm (L), ensuring coverage without restricting movement.

The coat features a slight A-line cut with 2cm of ease at the chest and hip, allowing room for wearing over lightweight fleece or sweaters while maintaining a streamlined profile to reduce snagging on backpacks or playground equipment.

Each batch undergoes hydrostatic head testing on five random samples per 1,000 units, with acceptance criteria requiring a minimum of 1,800mm after three minutes of water exposure. Colorfastness to light is evaluated per ISO 105-B02, targeting a rating of 4 or higher after 20 hours of xenon arc exposure.

Dimensional stability is assessed after five wash cycles at 30°C, with maximum allowable shrinkage of 3% in length and 2% in width. Snap retention strength is tested on 10 samples per lot, requiring minimum 12N force for release.

Visual inspection includes 100% checking for coating uniformity, seam integrity, and reflective strip placement under 500 lux lighting. Any sample showing thin coating, missed welds, or misaligned trims is removed from the lot.

Each raincoat is folded to a uniform size of 25cm x 20cm x 3cm and placed in a 0.05mm thick polyethylene bag with a printed label containing size, material code, and care instructions. Twenty units are packed into a standard corrugated carton measuring 42cm x 30cm x 25cm.

Cartons are marked with EAN-13 barcodes and include palletizing instructions for safe stacking up to 1.8m height. Gross weight per carton averages 4.8kg for Size S, 5.2kg for M, and 5.6kg for L, facilitating efficient handling in warehouse operations.

For export shipments, cartons are secured with PET strapping and corner boards to prevent shifting during transit. Moisture barriers are included in pallet loads for routes exceeding 30 days transit time or high-humidity climates.

The raincoat is suited for daily use in temperate climates with annual rainfall between 800mm and 1,500mm, such as eastern China, southern Europe, and the northeastern United States. It performs effectively in drizzle, light rain, and intermittent showers but is not designed for prolonged heavy downpours or wind-driven rain exceeding 20mm/hour.

Common applications include school commutes, playground use, and light outdoor activities like park visits or nature walks. The breathable coating prevents excessive heat buildup during active play, reducing discomfort compared to non-breathable alternatives.

In urban environments with reflective surfaces and low-angle sunlight, the high-visibility yellow color (Pantone 109C) combined with reflective strips enhances detection distance by drivers during dawn, dusk, or overcast conditions, contributing to pedestrian safety.

For technical specifications, customization requests, or sample evaluation, contact our engineering team to discuss your specific requirements.
